item |
value |
AC Voltage |
380V |
Rated Power |
2000mm |
Rated Speed |
3000RPM |
Model Number |
V3M-100-2R0T30U0M |
Brand Name |
VEINAR |
Place of Origin |
China |
Guangdong |
|
Frame |
100mm |
Motor Mounting Type |
Flange |
Warranty |
18 months |
Phase |
Single-phase |
Efficiency |
IE 2 |
Frequency |
50/60HZ |
Protect Feature |
Drip-proof |
Type |
Servo Motor |
Model |
V3M-100-2R0T30U0M |
Q: Which industries apply your servo drives?
A: Robotics, lithium battery, 3C, etc.
Q: What communication protocols are supported?
A: EtherCAT, Profinet, Modbus.
Do you provide custom servo products?
A: Yes, custom solutions available.
Q: What's the repeat positioning accuracy?
A: Up to 1μm.
Q: Which motors are compatible?
A: Linear motors, DD motors.
Q: How strong is your R&D team?
A: 12 experts with 10+ years' experience.
Q: What's the current loop bandwidth?
A: 3300Hz.
Q: What's the sampling frequency?
A: 625kHz.
Q: Work with third-party motors?
A: Yes, e.g., Panasonic, Nikon.
Q: Position settling time?
A: <5ms.
Q: What's the current loop frequency?
A: 625kHz
Q: Which chips are used in control?
A: FPGA + high-frequency MCU
Q: What's the repeat positioning accuracy?
A: Up to 1μm
Q: Current loop calculation time?
A: 1.6 microseconds
Q: What encoders are available?
A: 23-bit optical, 17-bit magnetic
Q: Speed fluctuation range?
A: ±1rpm
Q: EtherCAT sync cycle?
A: Up to 250us
Q: What's the current loop bandwidth?
A: 3300Hz
Q: Does it support precision compensation?
A: Laser data importable
Q: Compatible with which motors?
A: Linear motors, DD motors
